Intelligent Touch Display
24-hour timing
Auto defrost
Low noise
Cool/warm
Powerful dehumidifying
When season starts and heating demand is high, the Full-Inverter runs at 100% compressor & fan speed for fast heating.
When maintaining the pool temperature, the Full-Inverter runs at low speed for energy saving with higher COP.
| Model | SDT-3021-T | SDT-3024-T | SDT-3028-T | SDT-3031-T | SDT-3035-T | ||
|---|---|---|---|---|---|---|---|
| Performance (Heating) | |||||||
| A27°C/24.3℃, W26℃ | Heating Consumed power COP |
6.2-21.1 0.45-3.2 13.7-6.6 |
6.72-23.7 0.46-3.65 14.61-6.49 |
6.72-28 0.46-4.5 14.61-6.22 |
8.5-30.5 0.59-4.7 14.3-6.5 |
7.1-35.0 0.62-6.73 11.4-5.2 |
|
| A15℃/12℃, W26℃ | Heating Consumed power COP |
4.8-16.9 0.68-3.1 7.06-5.45 |
4.8-17.3 0.63-3.83 7.6-4.52 |
4.8-20.5 0.63-4.4 7.6-4.66 |
6.4-23.8 0.82-4.5 7.8-5.29 |
6.4-27.5 0.97-6.63 6.6-4.15 |
|
| Performance(Cooling) | |||||||
| A45℃/-℃, W40℃ | Cooling Consumed power EER |
2.8-11.9 0.7-4.5 4.0-2.64 |
2.9-13.2 0.73-5.5 3.96-2.4 |
2.9-13.2 0.73-5.5 3.96-2.4 |
4.76-15.5 1.21-6.1 3.93-2.54 |
4.76-15.7 1.21-6.2 3.93-2.53 |
|
| A35℃/24℃, W30℃ | Cooling Consumed power EER |
3.3-14.0 0.55-4.0 6.0-3.5 |
3.5-16.5 0.60-5.3 5.8-3.11 |
3.5-16.5 0.6-5.3 5.8-3.11 |
5.8-18.9 1.0-5.73 5.75-3.3 |
5.8-19.6 1.0-6.1 5.75-3.21 |
|
| Technical data | |||||||
| Power Supply | 220V-230V/1N/50HZ | ||||||
| Rated Current Throttling device |
A – |
18 |
24 |
24 EEV |
28 |
34 |
|
| Compressor Quantity Fan Quantity |
– PCS |
1 1 |
|||||
| Airflow Volume(max) Sound Pressure 1m Water Connection Water Flow Volume Water Pressure Drop (max) |
m³/h dB(A) mm m³/h kPa |
6000 48-55 50 9.0 16 |
6000 48-56 50 10.5 18 |
6600 48-56 50 12.0 20 |
8000 50-57 50 12.5 23 |
8000 53-59 50 14.6 25 |
|
| Refrigerant Operating air temperatur e (°C) |
– – |
R32 |
|||||
| OPERATION PRESSURE(LOW OPERATION Net Weight Shipping Weight |
Mpa MPa kg kg |
2.1 4.4 106 126 |
2.1 4.4 110 130 |
2.1 4.4 110 130 |
2.1 4.4 120 140 |
2.1 4.4 125 145 |
|
| Model | SDT-3035S-T | SDT-3048S-T | SDT-3057S-T | SDT-3115S-T | SDT-3225S-T | ||
|---|---|---|---|---|---|---|---|
| Performance (Heating) | |||||||
| A27°C/24.3℃, W26℃ | Heating Consumed power COP |
7.1-35.0 0.62-6.73 11.4-5.2 |
10.5-47.5 0.78-7.8 13.5-6.09 |
12.0-56.3 0.90-9.2 13.3-6.1 |
24.2-114 1.8-18.5 13.44-6.16 |
48.5-225 3.58-36.9 13.55-6.10 |
|
| A15℃/12℃, W26℃ | Heating Consumed power COP |
6.4-27.5 0.97-6.63 6.6-4.15 |
7.85-36.5 1.08-7.6 7.27-4.8 |
9.2-42.0 1.3-8.8 7.08-4.77 |
18.5-85.0 2.6-17.5 7.12-4.86 |
37.1-172 5.1-35.3 7.27-4.87 |
|
| Performance(Cooling) | |||||||
| A45℃/-℃, W40℃ | Cooling Consumed power EER |
4.76-15.7 1.21-6.2 3.93-2.53 |
5.7-24.3 1.46-9.2 3.9-2.63 |
6.4-26.2 1.68-9.5 3.81-2.75 |
12.8-52.5 3.35-20.0 3.82-2.63 |
25.5-105 6.75-40.2 3.78-2.61 |
|
| A35℃/24℃, W30℃ | Cooling Consumed power EER |
5.8-19.6 1.0-6.1 5.75-3.21 |
7.05-33.0 1.2-9.8 5.88-3.37 |
8.6-35.0 1.32-10.0 6.52-3.5 |
17.0-70.3 2.65-20.0 6.42-3.52 |
34.0-141 5.3-40.0 6.42-3.53 |
|
| Technical data | |||||||
| Power Supply | 380-415V/3N~/50Hz | ||||||
| Rated Current Throttling device |
A – |
15 EEV |
20 EEV |
21 EEV |
42 EEV |
85 EEV |
|
| Compressor Quantity Fan Quantity |
– PCS |
1 1 |
1 1 |
1 1 |
2 2 |
4 2 |
|
| Airflow Volume(max) Sound Pressure 1m Water Connection Water Flow Volume Water Pressure Drop (max) |
m³/h dB(A) mm m³/h kPa |
8000 53-59 50 14.6 25 |
11000 54-63 63 15.5 28 |
12000 56-64 63 18.0 30 |
24000 60-67 100 36.5 30 |
48000 65-71 100 74.0 34 |
|
| Refrigerant Operating air temperatur e (°C) |
– – |
R32 |
|||||
| OPERATION PRESSURE(LOW OPERATION Net Weight Shipping Weight |
Mpa MPa kg kg |
2.1 4.4 125 145 |
2.1 4.4 230 260 |
2.1 4.4 230 260 |
2.1 4.4 360 390 |
2.1 4.4 920 960 |
|
